The best sound quality achievable for traditional vinyl playback
The CLUB boasts the best specifications and best sound, making it an ideal choice for Club DJs in any environment: studio, broadcast or club.
• The CLUB features a Special-Elliptic stylus that allows for detailed sound quality: Special-Elliptic stylus fits better in the groove and therefore has more contact area with the groove itself, extracting more intricate details, than is possible with a spherical diamond.
• The CLUB’s 8 mV output voltage requires less gain from the preamps, providing cleaner sound reproduction and less susceptibility to feedback in live environments.
Stylus Type : Special Elliptical
Tracking Force: 3.0 g
Output Voltage: 8 mV
Frequency Range: 20–20.000 Hz
Features:
Output voltage at 1000Hz, 5cm/sec. - 8 mV Channel balance at 1kHz - 1 dB Channel separation at 1kHz - 25 dB Channel separation at 15 kHz - 15 dB Tracking ability at 315 Hz at recommended tracking force - 100 μm Compliance, dynamic lateral - 14 μm/m N Stylus type - Special Elliptical r/R 13/25 μm Tracking force range - 2 - 4 g Tracking force recommended - 3 g Internal impedance, DC resistance - 1000 Ohm Internal inductance - 650 mH Recommended load resistance - 47 kOhm Recommended load capacitance - 200-600 pF Cartridge weight - 18,5 g
