LASE Replacement 18" Speaker for JBL268G / Eon 518S
LASE Replacement 18" Speaker for JBL268G / Eon 518S
Regular price
£163.20 GBP
Regular price
£272.00 GBP
Sale price
£163.20 GBP
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
The LASE Replacement 18" Speaker is compatible with the following JBL models:
- Eon 518S
- PRX 618S
- JBL 268G
It is capable of reproducing full bandwidth sound at high levels and features a neodymium magnet along with dual voice coils that enable better performance over conventional designs at a fraction of the weight. Inline voice coils in separate magnetic gaps allow more efficient heat dissipation due to the added space, and the reverse-wound voice coils are placed in magnetic fields of opposite polarity. This 18" neodymium integrated woofer features dual 3" voice coils.
SPECIFICATIONS
- Nominal Diameter: 18"
- Power Handling
- RMS: 500 W
- Max: 1000 W
- Nominal Impedance: 4 Ω
- Sensitivity: 96 dB 1W/1m
- Voice Coil Diameter: 3"
- Shipping Weight: 13.85 lbs
SMALL SIGNAL PARAMETERS
- Resonant Frequency (Fs): 33 Hz
- Voice Coil Inductance (Le): 1.85 mH
- Mechanical Q (Qms): 3.8
- Electromagnetic Q (Qes): 0.39
- Total Q (Qts): 0.36
- Compliance Equivalent Volume (Vas): 11.58 ft.³
- Maximum Linear Excursion (Xmax): 8 mm
